Duncan 545
-
Model Duncan
-
Basic Vehicle Ford Transit Custom
-
Basic Engine 105 HP Engine
-
Technically permissible overall weight* 3.200 kg
* For safety reasons, the "technically permissible maximum laden mass" stated in the vehicle registration document must not be exceeded under any circumstances.
-
Weight in ready-to-drive state** 2.589 kg
** Dimensions in ready-to-drive state as per EU Directive No. 1230/2012: Vehicle with standard equipment according to manufacturer's specifications including driver (75 kg), 90% of filling quantity for fuel, 100% for water as well as gas (aluminium gas bottle 5 kg), without special equipment.
-
Bed shape Double bed in pop-up roof
-
Total length 5.340 mm
-
Sleeping areas 2 (4) optional
-
Seating areas 2 (4) optional
Info
Panorama
Serial Equipment Duncan
Technical Data
Info

Panorama
Please click the button below to load the content from Matterport Panorama.
With the loading of the panorama you accept the privacy policy of MatterPort
Mehr erfahren
Serial Equipment Duncan
Basic Vehicle
- Ford Transit Custom
- EURO 6D Final incl. soot particle filter
- Driver and Passenger Airbag
- ABS / ESP
- Manual air-conditioning system
- Cruise control
- Power steering
- Adjustable headlights
- Immobiliser
- 3-point seat belt system
- Electric window controls at the front
- Electrically adjustable heated exterior mirrors
- Remote control central locking system
- Decorative wheel trims
- Fix & Go breakdown kit
- Driver’s cab seat cover in living area upholstery fabric
- Front bumpers black
- Rear bumpers black
- Leather steering wheel
Superstructure Exterior
Living Area
Technical Data
Model: | Duncan 545 |
---|---|
Basic vehicle | Ford Transit Custom |
Basic motorization | 77 kW (105 HP) |
Fuel tank | 70 ltr + Ad Blue |
Technically permissible total weight* | 3200 kg |
Mass when ready to drive** | 2589 kg |
Permissible gross train weight with standard motor / higher motorization | 5240 kg (4200 kg for automatic) |
Trailerload, braked*** with standard motor / higher motorization | 2600 kg (1500 kg for automatic) |
Total length | 5340 mm |
Total width | 2080 mm |
Total height | 2080 mm |
Internal width | 1775 mm |
Standing height | 1406 / 2000-2030 mm |
Wheel base | 3300 mm |
Tyres | 6.5 x 16“ 215/65R16 |
Bed conversation seating unit | 1870 x 1140 mm |
Bed in the pop-up roof | 1780 x 1160 mm with extension 190 x 1020 mm |
Beds | 2 (4) |
Permissible number of passengers with 3-pt belt | 2 (4) |
Fresh water capacity complete | 40 l |
Wastewater capacity | 30 l |
Gas | 1 x 2.75 kg |
Battery capacity | 1 x 75 Ah |
Charger | 17 A |
Refrigerator | 42 l (with freezer) |
* For safety reasons, the “technically permissible maximum laden mass” stated in the vehicle registration document must not be exceeded under any circumstances.
** Dimensions in ready-to-drive state as per EU Directive No. 1230/2012: Vehicle with standard equipment according to manufacturer’s specifications including driver (75 kg), 90% of filling quantity for fuel, 100% for water as well as gas (aluminium gas bottle 5 kg), without special equipment.
*** the permissible gross train weight must be observed.
**** with 35 H chassis (option).
***** not in connection with 180 HP motor.
****** excluding DE 560, 570 and Duncan
******* reclining area can be extended to 1850/1750 x 1880 in lower position.
